AUTO DIALER

An autodialer is an electronic device that can automatically dial telephone numbers to communicate between any two points in the telephone, mobile phone networks. Once the call has been established (through the telephone exchange) the autodialer will announce verbal messages to the called party.

Features:

16 X 2 LCD for easy programming
16 keys multifunction soft touch key pad.
60 second message storage.
50 telephone numbers storage facility.
15 digit length telephone number to store Cell phone numbers,95 numbers and STD numbers.
Non Volatile memory for message storage and telephone number storage.
12 / 48 Volts operation AC/DC

Auto Dialer is an Electronic device which alerts you and your friends over phone/cell by playing the pre-recorded message.

Voice message: 60 seconds recorded message in your own voice in any language includes a common message to describe the location and short message to describe the alarm event.

Benefits: Save precious life and hard earned money.

Applications: Upgrading an existing alarm systems that do not have a Built-in dialer, House, Bank,Ofiice and Jewellery shops, etc.

Auto Dialer Programming method:

On power on condition press and hold `F4’ key. Release the key when the screen clears. Key in the password. Correct password will get you to the command menu. From the command menu select a key to perform functions.

Command Key:1
This function allows the user to store the telephone number that is to be dialed. The user may use any number between 0 to 9. The user may insert a pause between two numbers by pressing`F3’ key. The telephone number may be up to 15 digit including pause
command. Repeat the same command to add more telephone numbers. The user may store up to 50 telephone numbers.

Command Key: 2
This function allows the user to view the telephone number that is stored in the instrument. `Ent’ key to view the next telephone number and `F4’ key to view the previous number. F1 key may be used to dial current number, which is displayed on the screen.

Command Key: 3
This function allows the user to edit the phone numbers stored in the instrument.

Command Key: 4
This function allows the user to record two independent messages that is to be played. Press and hold `Ent’ key while recording your message. To end the recording release the `Ent’ key. The message length may be up to 60 seconds. If the user exceeds this limit the
program stops the recording automatically at 60th second.

Command Key: 5
This function allows the user to set pause time between end of dialing and message playing i.e. program will wait for set time after dialing telephone number before playing the message. The user may select 1 to 9 seconds as pause time.

Command Key: 6
This function allows the user to determine the number of calls to be made to the stored telephone numbers. If the set number is two then each stored telephone number will receive two calls from the dialer.

Command Key: 7
This function allows the user to determine the number of message repeation to a telephone number. If the set number is four then dialer will play the message four times to the dialed telephone number.

Command Key: 8
This function allows the user to set the pause time duration, which will be used when dialing numbers. This pause is useful where Auto Dialer is connected to and EPABX. The user may select 1 to 9 seconds as pause time.

Command Key: 9
This function allows the user to erase all the telephone numbers stored in the instrument.

Command Key:0
This function allows the user to erase all the telephone numbers stored in the instrument

Command Key:F1
This function allows the user to configure the Autodialer to Dial the stored number on Power on Condition or by External Trigger or by Continues External Trigger.

If Power On mode is selected the number will be dialed once the power is applied to the instrument. If the External Trigger is selected the auto dialer is always powered, and if the trigger pin is shorted it will start the dial process.

If the Continues External Trigger is selected the autodialer is always powred and if the trigger pin is shorted it will start the dial process and it will abort the porcess once the Trigger is opened.

Press 1,2 and 3 to change the selection.

Command Key:F2
This function allows the user to configure the Autodialer to Dial the stored number in Tone Mode (faster dialing mode) or in Pulse Mode. Please not that some telephone exchanges will not support Tone Mode.

Press 1 and 2 to change the selction.
